Enerdrive ePOWER 2000w/12v With RCD & AC Transfer Switch

AU$1544.00

2000W 12V True Sine Wave Inverter with AC Transfer Switch & Safety Switch

The 2000W 12V Inverter with AC Transfer & Safety Switch is one in a family of affordable, high quality, professional level inverters by Enerdrive | Dometic. By using the latest power conversion technology, our inverters deliver clean and energy efficient true sine wave AC power from your DC supply.

This Inverter incorporates a 16A AC Transfer Switch which allows for seamless AC power transfer between Mains/Generator and Inverter. This helps to keep your appliances running with almost no break time on AC transfer and allows for a much simpler installation on-board.

Also included in the unit is a RCD Safety Switch. This switch monitors the flow of electricity through the inverter and detects any problems that may pose a risk to personal safety and switches the output power off within 0.03 of a second.

The Enerdrive | Dometic 2000W is built to operate basic equipment such as power tools, computers, microwave ovens, televisions and other appliances that use up to 2000W of power for operation. All Enerdrive | Dometic inverters are covered by our extensive 5 Year warranty.

Features

Seamless 16A AC Internal Transfer Switch
AC RCD/Safety Switch with test button
Removable LED Remote Control Display Panel
Regulated Pure Sine Wave Output
Silent Operation
Compact Size for Easy Installation
USB Port for charging USB devices

	2000W 12V True Sine Wave Inverter with AC Transfer & Safety Switch	2000W 24V True Sine Wave Inverter with AC Transfer & Safety Switch	2600W 12V True Sine Wave Inverter with AC Transfer & Safety Switch


SKU	EN1120S-X	EN1120S-X-24V	EN1226S-X
AC Output Power	2000W	2000W	2600W
AC Output Current	8.7A	8.7A	11.3A
AC Output Voltage	230 Vac / 50 Hz	230 Vac / 50 Hz	230 Vac / 50 Hz
AC Output Waveform	Sinewave (<3% THD)	Sinewave (<3% THD)	Sinewave (<3% THD)
Nominal DC Input Voltage	12.5 VDC	24.5 VDC	12.5 VDC
No Load battery draw	< 1.5 ADC	< 1.5 ADC	< 1.5 ADC
DC Input Voltage operating range	10.5 – 15.5 VDC	21.0 – 31.0 VDC	10.5 – 15.5 VDC
Under Voltage Alarm	11.0 / 12.1 VDC	22.0 / 24.2 VDC	11.0 / 12.1 VDC
Under Voltage Alarm Recovery	11.3 / 12.3 VDC	22.6 / 24.6 VDC	11.3 / 12.3 VDC
Under Voltage Shutdown	10.5 / 11.8 VDC	21.0 / 23.6 VDC	10.5 / 11.8 VDC
Under Voltage Shutdown Recovery	12.0 / 12.6 VDC	24.0 / 25.2 VDC	12.0 / 12.6 VDC
Over Voltage Shutdown	15.5 VDC	31.0 VDC	15.5 VDC
USB Port	5V, 2.1A	5V, 2.1A	5V, 2.1A
AC Transfer Switch
Transfer Time	< 30 ms	< 30 ms	< 30 ms
Transfer Relay Rating	16A (resistive load)	16A (resistive load)	16A (resistive load)
AC Input socket IEC-C20	16A max	16A max	16A max
AC Output socket IEC-C19	16A max	16A max	16A max
AC Output Front GPO	10A max	10A max	10A max
Safety and Environmental
Conformance	All required Australian Standards , CE LVD: EN/IEC 62040-1, IEC61558-2-16	All required Australian Standards , CE LVD: EN/IEC 62040-1, IEC61558-2-16	All required Australian Standards , CE LVD: EN/IEC 62040-1, IEC61558-2-16
EMI / EMC	CE EMC: EN/IEC 62040-2 category C1	CE EMC: EN/IEC 62040-2 category C1	CE EMC: EN/IEC 62040-2 category C1
Agency Markings	RCM , CE	RCM , CE	RCM , CE
Operating Temperature	0°C to 40°C	0°C to 40°C	0°C to 40°C
Storage Temperature	-20°C to 60°C	-20°C to 60°C	-20°C to 60°C
Relative Humidity	5-90% non-condensing	5-90% non-condensing	5-90% non-condensing
Operating Altitude	Up to 3000 meters above sea level	Up to 3000 meters above sea level	Up to 3000 meters above sea level
Weights and Dimensions
Weight	5.9 kg	5.9 kg	7.0 kg
Dimensions (W x L x H)	444x230x115 mm	444x230x115 mm	560x230x115 mm
Warranty	5 Years	5 Years	5 Years

Showing 1 to 32 of 32 entries

Note: Specifications subject to change without notice.

Estimate Run Time On Load

Following run times are estimates for reference, based on using different battery bank sizes. Actual run times may vary.

Important: Power Drain from DC Battery Bank.

Please note that there is a power drain of approx 700mA from the battery bank when the Inverter is running in AC By-Pass mode. In order to avoid draining down the battery bank, a battery charger with sufficient power is required to maintain the battery bank voltage.

	Estimate run time on different 12V Battery Bank Size
AC Load	60AH	120AH	180AH	240AH	300AH
50 W	11 hrs	22 hrs	33 hrs	44 hrs	55 hrs
100 W	5 hrs	11.5 hrs	17 hrs	23 hrs	29 hrs
200 W	2.5 hrs	5 hrs	8 hrs	11 hrs	13.5 hrs
500 W	49 mins	2 hrs	3 hrs	4 hrs	5 hrs
1000 W	15 mins	49 mins	1.5 hrs	2 hrs	2.5 hrs
1500 W	8 mins	27 mins	49 mins	1 hrs	1.5 hrs
2000 W	N.R.	15 min	34 mins	49 mins	1 hrs
2600 W	N.R.	11 min	25mins	37 mins	49 mins

Note: Specifications subject to change without notice.
